800W RGB + White + Amber LED Stage Strobe Light

Light Source & Optical

• LEDs: 648 × 5050 RGB LED + 288 × 2835 White SMD LED + 144 × 2835 Cool White + Amber LED (1,080 total)
• Effect zones: 32 White Strobe + 8 Amber / Cool White + 72 RGB (independently controllable)
• Beam angle: 135° ultra-wide
• Strobe rate: 0 to 20 flashes / second (adjustable)
• Built-in effects: 20 static colors + built-in effect banks with foreground/background color control
• Sound sensitivity: 15 levels (3 sound modes)
• Auto mode speed: 255 levels (slow to fast)

Control & Connections

• Control modes: DMX-512, Master-Slave, Auto, Sound Active, Static Color, Strobe (6 total)
• DMX channel modes: 18 CH (standard) or 268 CH (full pixel mapping)
• DMX map (18 CH): CH1 master dim, CH2 strobe, CH3–5 RGB, CH6 built-in effect (RGB), CH7 effect speed, CH8 background dim, CH9 effect background color, CH10 strobe, CH11 white dim, CH12 built-in effect (white), CH13 effect speed, CH14 strobe, CH15 cool white dim, CH16 amber dim, CH17 built-in effect (CW+A), CH18 effect speed
• DMX map (268 CH): full per-pixel control across all 32 white zones, 8 amber/CW zones, and 72 RGB zones
• Connectors: 3-pin XLR DMX In / DMX Out + Power In / Power Out (daisy-chain)
• Display: 4-digit LCD with MENU / UP / DOWN / ENTER buttons
• Power daisy-chain: Up to 4 units on 110V power link

Electrical & Physical

• Power consumption: 800W
• Input voltage: AC 110–240V, 50/60Hz (wide-voltage, universal)
• Housing: Metal case with tempered glass front panel, IP20 (indoor use only)
• Cooling: Internal cooling fan with rear heat sink
• Max ambient temperature: 104°F (40°C)
• Minimum distance to flammable materials: 8 in (0.20 m)
• Minimum distance to objects/surfaces: 1.6 ft (0.5 m)
• Mounting: Integrated bracket with adjustment knobs — supports floor stand, hanging upside-down, or side truss (M10 clamp + safety cable required for overhead)
• Dimensions: 18.9 × 5.1 × 10.4 in (48 × 13 × 26.5 cm)
• Weight: 10.6 lb (4.8 kg)

Installation

• Position: Mount on a floor surface, hang upside-down from truss, or clamp sideways on a T-bar — all three orientations are fully supported by the integrated bracket.
• Overhead safety: Always use an M10 mounting clamp (not included) plus a safety cable rated to 12× the fixture weight. The rigging structure must support 10× the fixture weight.
• Clearance: Keep the fixture at least 8 in (0.20 m) away from flammable materials and pyrotechnics, and 1.6 ft (0.5 m) from any object or surface.
• Ventilation: Ensure open airflow around the rear heat sink and fan; do not enclose the fixture in a tight space.
• Electrical: Use a qualified electrician for permanent installation. Never plug the fixture into a dimmer pack. Do not exceed 4 daisy-chained units on 110V power link.

Cleaning

• Front panel: Wipe the tempered glass with a lens-safe cleaner monthly to maintain full brightness.
• Housing: Wipe the metal case with a soft, dry cloth after each event to remove dust and fog residue.
• Power off: Always disconnect from the mains before cleaning.

Maintenance

• Cool-down: Allow 15 minutes for the fixture to cool before servicing or repacking — 800W runs hot.
• Storage: Store in original packaging in a dry, dust-free space between events.
• Inspection: Check the mounting bracket, clamps, safety cable, DMX connectors, and power cord before every install.

For detailed instructions, check out the user guide.
